JG-GI18-08N1
| Technical parameters | |
| Set distance | 0~8mm ±10% |
| Standard detected object | 30x30x1mm |
| Power supply voltage | 6-36 VDC / 90-250 VAC |
| Switching point offset | <±10% |
| Load current | <300mA |
| Drop | <2.5V |
| Consumption current | <10mA |
| Hysteresis range | 1% ~ 20% |
| Repeated precision | <3% |
| Switching frequency | DC-200Hz / AC-25Hz |
| Output indicator | LED |
| Polarity protection | yes |
| Surge protection | yes |
| Short circuit protection | yes |
| Ambient temperature | -25°C ~ +70°C |
| Ambient humidity | 35% ~ 95% |
| Protection grade | IP67 |
| Shell material | nickel plated brass |
| Connection | 1.5m PUR |
