JG-0910/01 – JG-9511
| Specification | ||||||||||
| Type | JG0910 | JG1210 | JG1810 | JG 2510 | JG 3210 | JG 4011 | JG 5011 | JG 6511 | JG 8011 | JG 9511 |
| JG 0901 | JG1201 | JG1801 | JG 2501 | JG3201 | ||||||
| Rated Insulation (V) | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 |
| Conventional Thermal Current (A) | 20 | 25 | 32 | 40 | 50 | 60 | 75 | 80 | 110 | 125 |
| Rated operational current 380V/ac3 | 9 | 12 | 16 | 25 | 32 | 40 | 50 | 63 | 80 | 95 |
| Controlled power (kw) | 2.2 | 3 | 4 | 5.5 | 11 | 15 | 18.5 | 22 | 25 | |
| 4 | 5.5 | 7.5 | 11 | 18.5 | 22 | 30 | 37 | 45 | ||
| 4 | 5.5 | 9 | 11 | 22 | 25 | 37 | 45 | 45 | ||
| 4 | 5.5 | 9 | 11 | 22 | 30 | 37 | 45 | 45 | ||
| 5.5 | 7.5 | 10 | 15 | 30 | 33 | 37 | 45 | 45 | ||
| Install way | 1.use 2 scews 2 use 35mm installation rail | 1.use 3 scews 2 use 35mm or 75mm installation rail (with moulded coil) | ||||||||
